The foam cutter is a hot filament cutter which we promotes. This machine is characterized by its optimized design, large processing scope, and simple operations. It uses 0.5 millimeter heating wire, which allows quicker heat release and is extremely steady, nimble, agile, and has a high degree of fineness. By using advanced computer design, instead of manually cutting, you now have automated, computer controlled cutting, resulting in much higher efficiency. It's a new machine in the foam cutting industry and can be used in advertising, billboards and the cast iron industry to replace wooden moulds.
Specification:
Name: FC-1412 Foam Cutter
Max Cutting Speed:0-1200mm/min
X-Travel: 1400mm
Y-Travel: 1200mm
Wire Diameter: ∮0.5mm
Allow Material Thickness: 500mm
Working Area (X.Y): 1850x600mm
External Size (W.L.H): 1960x1000x1660mm
Power Source: AC220V±10% 50Hz
Weight: 80kg
Consumption:0.8 Kw
**Parameters are subject to change.use the company technical standards as the basis.
|
